מעבד
|
Intel Core i5-10400 Processor
2.9 GHz Base frequency, up to 4.3 GHz maximum turbo frequency with Intel Turbo Boost Technology
12 MB cache, 6 cores, and 12 threads
Intel UHD Graphics 630
Supports DDR4 memory up to 2666 MT/s data rate
|
|
ציפצט
|
Intel Q470
|
|
זיכרון
|
16GB DDR4
Number of slots: (2) DIMMs (customer accessible/upgradeable)
Up to 2666 MT/s and 3200 MT/s
NOTE: Memory modules support data transfer rates up to 2666 MT/s and 3200 MT/s depending on memory module used; actual data rate is determined by the system configured processor.
All memory slots are customer accessible/upgradeable.
|
|
איחסון
|
256 GB M.2 2280 PCIe NVMe SSD
|
|
מערכת הפעלה
|
Windows 11 Professional
|
|
רשת
|
תיאור תכונה
Ethernet (RJ-45)
Intel I219-LM Gigabit Network Connection LOM (סטנדרטי)
Intel Ethernet I210-T1 PCIe x1 Gb כרטיס ממשק רשת (אופציונלי)
הערה: המונח "10/100/1000" או "Gigabit" Ethernet מציין תאימות לתקן IEEE 802.3ab עבור Gigabit Ethernet, ואינו מציין מהירות פעולה בפועל של 1 Gb/s. עבור שידור במהירות גבוהה, נדרש חיבור לשרת Gigabit Ethernet ותשתית רשת.
אַלחוּט
Intel Wi-Fi 6 AX201 802.11ax (2×2) עם Bluetooth M.2 Combo Card vPro
Intel Wi-Fi 6 AX201 802.11ax (2×2) עם Bluetooth M.2 Combo Card ללא vPro
Realtek RTL8822CE 802.11ac (2×2) עם כרטיס Bluetooth M.2 Combo
Realtek RTL8821CE 802.11ac (1×1) עם כרטיס Bluetooth M.2 Combo
הערה: Wi-Fi 6 תואם לאחור למפרטי 802.11 קודמים.
נקודת גישה אלחוטית ושירות אינטרנט נדרשים ואינם כלולים. זמינות נקודות גישה אלחוטיות ציבוריות מוגבלת. המפרטים עבור 802.11 WLAN הם מפרטי טיוטה ואינם סופיים. אם המפרט הסופי שונה ממפרטי הטיוטה, זה עלול להשפיע על יכולתו של המחשב הנייד לתקשר עם התקני 802.11 WLAN אחרים.
|
|
אודיו
|
Integrated Realtek Conexant CX20632
(1) 3.5 mm Headset connector supports an OMTP or CTIA style headset and is re-taskable as a Line-in, Line-out, microphone-in or headphone-out port
(1) Headphone port
(1) Rear Line-out
2 W per channel class D mono amplifier (for internal speakers only)
NOTE: External speakers must be powered.
|
|
ספק כח
|
180 W active PFC
87/90/87% efficient at 20/50/100% load (115 V)
90/92/89% efficient at 20/50/100% load (230 V)
|
|
מידות
|
Chassis (W x H x D) (not including bezel)
269.24 x 93.98 x 297.18 mm (10.6 x 3.7 x 11.7 in)
System volume
634 cu in
10.4 L
System weight
4.53 kg (9.99 lbs)
Maximum supported weight (desktop orientation)
35 kg (77.16 lbs)
Packaged (H x W x D)
499.11 x 399.03 x 230.12 mm (19.65 x 15.71 x 9.06 in)
Shipping weight
7.32 kg (16.14 lbs)
Palletization profile
6 units per layer; 10 layers maximum; 60 per pallet
Footprint 1199.90 x 1000.0 x 2400.05 mm (47.24 x 39.37 x 94.49 in)
|
|
יציאות וכניסות
|
(2) USB 2.0 Type-A ports (rear)
(2) USB 2.0 Type-A ports (front)
(3) USB 3.2 Gen 1 Type-A ports (rear) 5 Gbps signaling rate
(2) USB 3.2 Gen 2 Type-A port (front) 10 Gbps signaling rate
(1) RJ-45 (network) connector (rear)
(1) DisplayPort 1.4 connector (rear)
(1) HDMI 1.4 (rear)
(1) Microphone/headphone combo jack (front) CTIA and OMTP headset support
(3) Internal SATA port
(1) Internal M.2 PCIe x4 2280 (for storage)
(1) Internal M.2 PCIe x1 2230 (for WLAN)
(2) Internal PCIe x1 Gen 3
(1) Internal PCIe x16 Gen 3
Optional port (any one)
(2) USB 3.2 Gen 1 Type-A ports
(1) USB 3.2 Gen 2 10 Gbps signaling rate port with DisplayPort Alt Mode
(1) DisplayPort 1.4, or VGA, or HDMI 2.0 port (rear)
(1) Serial (RS-232)
NOTE: Must be configured at the time of purchase.
|
