Printer Specifications
|
Print Method
Thermal Transfer, Direct Thermal
Print Speed
SLP-TX400: Up to 7 ips (178 mm/sec)
SLP-TX403: Up to 5 ips (127 mm/sec)
Print Resolution
SLP-TX400: 203 dpi
SLP-TX403: 300 dpi
Print Width
SLP-TX400: Up to 108 mm
SLP-TX403: Up to 105.7 mm
Print Length
Up to 1,000 mm
Sensor
Transmissive, Reflective (Adjustable),
Ribbon-End, Head open
|
|
Performance Characteristics
|
Memory
64 MB SDRAM, 128 MB Flash
Interface
Standard: USB + Serial + Parallel
Optional: ¡§ח USB + Serial + Ethernet + WLAN©צ
¡§ט USB + Serial + Ethernet + Bluetooth©ק
SLP-TX400R(RFID)
USB + Serial + Ethernet + Bluetooth©ק / WLAN©צ
+ RFID
----------------------------------------------------------------
WLAN©צ: 802.11a/b/g/n/ac USB dongle type
(Optional)
Bluetooth©ק: USB dongle type (Optional)
Real Time Clock
Supported
|
|
Fonts / Graphics / Symbologies
|
Fonts
• 10 SLCS Resident Bitmap Fonts
• One SLCS Resident Scalable Font
• 16 BPL-Z¢ג Resident Bitmap Fonts
• One BPL-Z¢ג Resident Scalable Font
• 5 BPL-E¢ג Resident Bitmap Fonts
• 23 Code Page
• Unicode supported
(UTF-8, UTF-16LE, UTF-16BE)
Graphics
Supporting user-defined fonts, graphics,
formats, and logos
Barcode Symbologies
1D: Codabar, Code 11, Code 39, Code 93,
Code 128, EAN-13, EAN-8, Industrial 2-of-5,
Interleaved 2-of-5, Logmars, MSI, Plessey,
Postnet, GS1 DataBar (RSS-14),
Standard 2-of-5, UPC / EAN extensions,
UPC-A, UPC-E, IMB
2D: Aztec, Codablock, Code 49, Data Matrix,
MaxiCode, MicroPDF417, PDF417, QR code,
TLC 39
|
|
Media Characteristics
|
Media Type
Gap, Black Mark, Notch, Continuous, Fan-Fold
Media Width
25 ~ 112 mm
Media Roll Diameter
Up to 130 mm
Media Thickness
0.06 ~ 0.20 mm
Supply Method
Easy Paper Loading
Inner Core
25.4 ~ 38.1mm
|
|
Ribbon Characteristics
|
Ribbon Type
Wax, Wax/Resin, Resin, Outside
Ribbon Width
33 ~ 110 mm
Ribbon Length
Up to 300 m
Core Inner Diameter
25.4 mm, 12.5 mm
|
|
Environment Characteristics
|
Temperature
Operating: 5 ~ 40¢®ֹ (41 ~ 104¢µ)
Storage: -20 ~ 60¢®ֹ (-4 ~ 140¢µ)
Humidity
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH
|
|
Software
|
Emulation
SLCS¢ג, BPL-Z¢ג, BPL-E¢ג
Driver / Utility
Windows Driver (Europlus / Seagull),
Linux / Mac CUPS Driver,
Virtual COM USB / Ethernet Driver,
Utility Program, OPOS / JPOS Driver,
Bartender Ultralite for BIXOLON, Label Artist-II¢ג,
SAP¢ח Device Driver
SDK / Plugin
Android / iOS / Windows SDK, Linux SDK,
Chrome SDK, Xamarin SDK
Application
Label Artist¢ג Mobile (Android, iOS),
mPrint App (iOS), mPrint Server (Windows, iOS)
MDM
BIXOLON Profile Manager
- XPM¢ג, XCM¢ג (Windows, Android)
|
|
Accessories
|
Options
RFID, Peeler, Auto Cutter, External Paper Supply,
WLAN Dongle(Consensus required)
|
|
RFID
|
RFID
Frequency
UHF, 865 ~ 868MHz(EU),
902 ~ 928MHz(KR, USA, CHN)
Transmit Power
1W
Modulation
ASK
Protocol
UHF EPC Class 1 Gen 2 V1.2/ ISO 18000-6C
Auto Cutter
Optional
Tag Pitch
Min 25mm
|
|
Physical Characteristics
|
Dimensions (WxDxH)
214 x 310 x 195 mm
(8.42 x 12.20 x 7.67 inch)
Weight
2.85 kg (6.28 lbs.)
Electrical
EnergyStar Certified,
External Power Adaptor 100-240V AC, 50/60Hz
|
|
