מפרט
|
CPU Intel Xeon E3-1230v2 quad-core 3.3GHz
Hardware encryption engine Yes (AES-NI)
Memory 4GB DDR3-1600 ECC RAM (expandable up to 32GB)
Compatible drive type 12 x 3.5" or 2.5" SATA 6Gb/s (hard drives not included)
Maximum internal raw capacity 96TB (12 x 8TB HDD) (The actual capacity will differ according to volume types)
External ports USB 3.0 x 2, USB 2.0 x 2, Expansion port (Infiniband) x 2
Size (HxWxD) 88 mm x 445 mm x 570 mm
Weight 13.3 kg
LAN 1GbE (RJ-45) x 4
PCIe 3.0 x8 slot Two running at x8 mode, supports two dual-port 10GbE network interface cards
Wake on LAN/WAN Yes
Wireless support (dongle) Yes
AC input power voltage 100V to 240V AC
Power frequency 50 / 60Hz, single phase
Operating temperature 5 to 35°C (40 to 95°F)
Storage temperature -20 to 60°C (-5 to 140°F)
Relative humidity 5% to 95% RH
|
|
כללי
|
Networking protocols SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™, L2TP)
File system Internal: Btrfs, ext4
External: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT3
Storage management Maximum single volume size: 108TB/200TB (32GB RAM required, for RAID 5 or RAID 6 groups only); maximum internal volume: 1024,
maximum iSCSI target: 64, maximum iSCSI LUN: 512, RAID clone/snapshot support; Synology Expansion Unit support: RX1217/RX1217RP
Supported RAID type Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
File sharing capability Maximum user account: 16000; maximum group: 512; maximum shared folder: 512; maximum concurrent SMB/AFP/FTP/File Station connections : 1024
Privilege Windows Access Control List (ACL)
Virtualization VMware vSphere 5, Microsoft Hyper-V, Citrix certified
Directory service Windows AD integration: Domain Users login via Samba (SMB)/AFP/FTP/File Station, LDAP integration
Security FTP over SSL/TLS, IP auto-block, firewall, encrypted network backup over Rsync, HTTPS connection
Utilities Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator,
Photo Station Uploader, Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI
Supported clients Windows 7 onwards and Mac OS X® 10.10 onwards
Supported browsers Chrome™, Firefox®, Internet Explorer® 9 onwards, Safari® 8 onwards, Safari (iOS® 7 onwards on iPad®), Chrome (Android 4.0 onwards on tablets)
|
|
יישומים
|
File Station Virtual drive, remote folder, Windows ACL editor, compress/extract archived files, bandwidth control for specific users or groups, create sharing links, transfer
logs
Backup solutions Network backup; local backup; desktop backup; configuration backup; OS X Time Machine; backup data to public cloud;
shared folder sync - maximum task number: 16
FTP Server Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocols, boot over the network with TFTP
and PXE support, transfer logs
High Availability Manager Combines two RS3617xs into one high-availability cluster
Security Advisor Malware detection/removal, user account/password, network, system-related security scan
iOS/Android™ applications DS cloud, DS file, DS finder, DS cam, DS note, DS audio, DS download, DS photo, DS video
Windows Phone® applications DS file, DS finder, DS audio, DS download, DS photo, DS video
|
|
חבילות תוספות
|
Antivirus Essential Full system scan, scheduled scan, white list customization, virus definition auto update
Cloud Station Server Maximum concurrent file transfers: 1024, retain historical and deleted file versions
Cloud Sync One or two-way synchronization with public cloud storage providers including Amazon Cloud Drive, Amazon S3-compatible storage, Baiduyun, Box,
Dropbox, Google Cloud Storage, Google Drive, hubiC, Megafon Disk, Microsoft OneDrive, OpenStack Swift-compatible storage, WebDAV servers, Yandex Disk
DLNA/UPnP® Media Server DLNA certified, PS3®/PS4®/Xbox 360®/Xbox One® support
Download Station Supported download protocols: BT/HTTP/FTP/NZB/eMule; Maximum concurrent download task: 80
Log Center SSL connection, log rotation: 6 months, 1 year, 2 years, 3 years, email notification
MailPlus Intuitive webmail interface for MailPlus Server; customizable mail labels, filters and user interface
MailPlus Server Secure, reliable, and private mail server solution with High-availability, load balancing, security and filtering design
(Including free MailPlus licenses for 5 mail accounts. Procurement of additional licenses is required.)
Note Station Rich-text note organization with versioning, encryption, sharing, media embedding and attachments
Storage Analyzer Volume and quota usage, total size of files, volume usage and trends based on past usage, size of shared folders, largest/most/least frequently modified files
Surveillance Station Maximum IP camera: 75 (total of 2250 FPS at 720p, H.264) (Including two free camera licenses. Procurement of additional licenses is required.)
VPN Server Maximum connections: 30; supported VPN protocols: PPTP, OpenVPN™, L2TP
Web Station Virtual host (up to 30 websites), PHP/MariaDB®, 3rd-party applications support
Other packages Photo Station, Audio Station, iTunes® Server, 3rd-party packages
|
|
סביבת עבודה
|
Environment RoHS compliant
Package content RS3617xs main unit, Quick Installation Guide, accessory pack, AC power cord
Optional accessories Camera License Pack, VS360HD, Synology RKS1317 - Rail Kit Sliding, 4GB and 8GB DDR3 ECC RAM module, Synology Expansion Unit (RX1217/RX1217RP x 2),
10Gbps Ethernet adapter E10G17-F2 / E10G15-F1
Certification FCC: Class A, CE: Class A, BSMI: Class A
Warranty 5 years
|
